TE Connectivity AMP Connectors CT series, 292174-4, Board to Cable/Wire header, 2.00mm pitch, 4 positions, single row, SMD, shrouded - 4 wall, detent lock, tin-plated contacts, UL94 V-0 natural nylon.
| Parameter | Value |
|---|---|
| Series | CT |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 125VAC |
| Current rating | Varies by Wire Gauge |
| Contact material | Brass |
| Insulation color | Natural |
| Insulation height | 0.307\" (7.80mm) |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Board Guide, Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 4 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.177\" (4.50mm) |
The 292174-4: The shrouding protects the 0.177" (4.50mm) mating pins from damage during cable assembly, and the detent lock gives a positive hold against vibration — no secondary latch needed.
The natural nylon housing carries UL94 V-0 flame rating.
Listed as Active with no successor or end-of-life notice published. ROHS3 compliant.
0.079" (2.00mm) pitch, single row, 4 positions loaded. The 2.00mm pitch matches the standard CT series footprint.
Yes, ROHS3 Compliant per the listing.
