Mini CT 3-Pin Header for Board-to-Cable Wiring
It carries 3 positions on a 1.50mm pitch, with a full 4-wall shroud and a detent lock that gives a positive click on mating — no risk of the cable plug backing out under light vibration. The tin-plated contacts (39.4µin on the mating surface) are suited for moderate mating-cycle duty in general-purpose equipment — think control boxes, small appliances, or interior automotive modules where the connector stays mated for the product's life.
Shrouded Housing and Detent Lock Fit
The detent lock engages with a distinct snap — no separate latch to flip, no secondary lock to forget. This is a one-hand mate, which matters when you're wiring a panel in a tight enclosure. The 0.118" (3.00mm) post length is a standard through-hole fit for 1.6mm PCBs.
