TE Connectivity AMP Connectors Mini CT, 292230-8, Board to Cable/Wire header, 8 circuits, 1.50mm pitch, single row, SMT, shrouded - 4 wall, detent lock, tin-plated contacts, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Mini CT |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 50VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -30°C~105°C |
| Contact material | Brass |
| Insulation color | Beige |
| Insulation height | 0.272\" (6.91mm) |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Board Guide |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.094\" (2.40mm) |
The 292230-8: Surface-mount termination with a board guide feature that aligns the part during reflow — the 0.272" (6.91 mm) insulation height gives the SMT tails clearance above the board. The detent lock mates with the corresponding Mini CT receptacle housing; the tin-on-tin contact finish is rated for general-purpose duty where the connector is mated infrequently.
Sourced through independent distribution against an RFQ. No stock-holding claim; availability and pricing confirmed at quote time.
Yes — the 292230-8 is a Mini CT series header and mates with the corresponding Mini CT receptacle housing. The detent lock engages with the female housing latch, and the 1.50 mm pitch and 8-circuit single-row layout must match the receptacle's circuit count and keying.
