TE Connectivity AMP Connectors Mini CT header, order code 292232-5, 5 positions, single row, 1.50 mm pitch, 50 VAC, tin-plated mating contacts, surface-mount, solder termination.
| Parameter | Value |
|---|---|
| Series | Mini CT |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 50VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -30°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Beige |
| Insulation height | 0.272\" (6.91mm) |
| Insulation material | Polyamide (PA), Nylon, Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) |
| Features | Board Guide, Pick and Place |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.059\" (1.50mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.094\" (2.40mm) |
The 292232-5 is the 5-circuit member of TE's Mini CT header line, a single-row board-to-wire header with 1.50 mm pitch. Tin-plated mating contacts rated 50 VAC, surface-mount solder termination, and a shrouded 4-wall housing with detent lock.
The 4-wall shroud and detent lock protect the contacts during mating and resist vibration-induced separation. A board guide and pick-and-place feature aid SMT assembly.
The 292232-5 mates with a Mini CT receptacle housing that accepts the corresponding crimp terminals.
The 292232-5 carries UL94 V-0 flammability rating. RoHS and REACH compliance documentation is available from TE Connectivity upon request.
