36-Position Shrouded Header for Wire-to-Board
The 0.100" (2.54mm) pitch and 0.100" row spacing match the standard IDC ribbon cable footprint. Rated 1A per contact at 250VAC, with a UL94 V-0 PBT housing and gold-over-phosphor-bronze contacts — 30.0µin gold on the mating surface, 100.0µin tin on the post.
Mating Half and Keying Details
The header mates with AMP-Latch IDC socket connectors (strain-relief or standard) that accept 0.100" pitch ribbon cable. The keying slot in the shroud ensures correct orientation — a mis-mated pair is mechanically blocked before the contacts touch.
