TE Connectivity AMP Connectors MTA-100 header, 3-641216-3: 3-position single-row right-angle through-hole header, 0.100" (2.54 mm) pitch, gold-plated male pins, friction lock, UL94 V-0 natural thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | MTA-100 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Friction Lock |
| Voltage rating | 250VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Natural |
| Insulation height | 0.225\" (5.72mm) |
| Insulation material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 1 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact length - post | 0.140\" (3.56mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.295\" (7.49mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The friction lock keeps the mating housing seated under cable strain or vibration – a practical feature for wire-to-board connections in equipment that sees movement or service access.
The 0.225" (5.72 mm) insulation height and 0.295" (7.49 mm) mating pin length provide clearance for the mating housing latch and wire exit, while the 0.140" (3.56 mm) post length fits standard 1.6 mm PCBs.
The 3-641216-3 is sourced through independent distribution. Submit an RFQ for current pricing and availability – confirmed at quote time against your BOM quantity.
The 3-641216-3 mates with a standard MTA-100 receptacle housing (single-row, 0.100" pitch) using the matching crimp terminals. The friction lock engages with the receptacle latch.
