TE Connectivity AMP Connectors MTA-100 series, Board to Cable/Wire, Header, Male Pin, 3 Positions, 0.100" (2.54 mm) Pitch, Surface Mount, Solder Termination, Tin Contact Finish, Friction Lock, UL94 V-0, Black Insulation, -55°C ~ 105°C, 250VAC
| Parameter | Value |
|---|---|
| Series | MTA-100 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Friction Lock |
| Voltage rating | 250VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.347\" (8.81mm) |
| Insulation material | Polyamide (PA46), Nylon 4/6 |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 1 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.290\" (7.37mm) |
It mates with standard MTA-100 crimp receptacles for a board-to-cable/wire connection. Surface mount termination suits reflow assembly, saving a wave-solder pass compared to through-hole headers.
The shrouded wall on one side protects the mating pins from bent-contact damage during blind mating.
The pin pitch is 0.100" (2.54 mm), standard for the MTA-100 series.
It is a surface mount (SMD) header with solder termination, designed for reflow assembly.
Yes, it is ROHS3 compliant.
