TE Connectivity AMP Connectors MTA-100, Header, 3 Positions, 0.100" (2.54mm) Pitch, Surface Mount, Male Pin, Gold Mating Contact, Friction Lock, UL94 V-0
| Parameter | Value |
|---|---|
| Series | MTA-100 |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Friction Lock |
| Voltage rating | 250VAC |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.347\" (8.81mm) |
| Insulation material | Polyamide (PA46), Nylon 4/6 |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 1 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.290\" (7.37mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
It uses a 0.100" (2.54mm) pitch and surface-mount termination, with male square pins that mate with standard MTA-100 receptacle housings.
At 3 positions and a single row, this header is the smallest position count in the MTA-100 SMT family. The insulation height of 0.347" (8.81mm) and mating pin length of 0.290" (7.37mm) set the stack height when mated.
Yes, 3-647167-3 is ROHS3 compliant.
Yes, it features a friction lock for positive retention with the mating receptacle housing.
