TE Connectivity AMP Connectors Micro MATE-N-LOK header, order code 3-794622-2, 2 positions, dual row, 0.118" (3.00 mm) row spacing, 250 V, gold-plated mating contacts, surface-mount right-angle, solder termination, board lock.
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.290\" (7.37mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Positions | 2 |
| Row spacing - mating | 0.118\" (3.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 3-794622-2 is the 2-circuit member of TE's Micro MATE-N-LOK shrouded header line, a board-to-wire interconnect for general-purpose power distribution. Gold-plated mating contacts rated 250 V, dual-row 0.118" (3.00 mm) row spacing, and a surface-mount right-angle termination with integrated board lock for reflow retention.
The style is Board to Cable/Wire, and the series is Micro MATE-N-LOK.
