TE Connectivity AMP Connectors 3-794679-8 — Pin Headers

3-794679-8 TE Connectivity Micro MATE-N-LOK Header, 8 Pos

MPN3-794679-8
Active

TE Connectivity Micro MATE-N-LOK header, 3-794679-8, 8 positions, 2-row, 3.00mm pitch, right-angle through-hole, gold-plated mating contacts, shrouded with locking ramp, board lock, UL94 V-0, -40°C to 105°C.

$3.3300Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesMicro MATE-N-LOK
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

3-794679-8 key specifications
ParameterValue
SeriesMicro MATE-N-LOK
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating250V
Current ratingVaries by Wire Gauge
Operating temperature-40°C ~ 105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.290\" (7.37mm)
Insulation materialPolyamide (PA), Nylon

All specifications

3-794679-8 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageTray
FeaturesBoard Lock
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose
Contact shapeSquare
Rows2
Pitch0.118\" (3.00mm)
Positions8
Row spacing - mating0.118\" (3.00mm)
Contact finish - postTin
Contact finish - matingGold
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Board layout and footprint fit

The 3-794679-8: This is an 8-position, dual-row header on 3.00mm pitch — the same row-to-row spacing of 3.00mm means the PCB footprint is a 2x4 grid with 3.00mm centers in both axes.

Mating and locking

The shrouded 4-wall housing with locking ramp mates with the Micro MATE-N-LOK receptacle housing (e.g., 3-794656-8 for 8 positions). The ramp locks audibly on full engagement and resists accidental unmating under vibration. The header accepts male pins from the receptacle side — the contact interface is gold-on-gold when using the matching gold-plated receptacle terminals.

Frequently asked questions

Is 3-794679-8 RoHS compliant?

Yes, RoHS compliant per TE Connectivity's declaration.

What is the compatible receptacle for 3-794679-8?

The mating half is a Micro MATE-N-LOK receptacle housing, such as TE part number 3-794656-8 (8-position, dual-row). Use the matching crimp terminals (gold-plated for high-cycle applications).
