2-position header for low-circuit wire-to-board
The 3-794680-2 is a 2-position, 2-row Micro MATE-N-LOK header from TE Connectivity AMP Connectors, designed for board-to-cable/wire applications where only a single signal or power pair is needed. The 0.118" (3.00mm) row spacing keeps the footprint compact, while the full 4-wall shrouding protects the square male pins from bending during handling and mating.
Board lock and through-hole termination
Through-hole solder termination gives a robust mechanical bond suited for boards that see thermal cycling or moderate mechanical stress. The contact length — post is 0.125" (3.18mm), a standard length for single-sided boards or boards with thin dielectric stacks. The insulation height of 0.364" (9.25mm) leaves clearance for components on the opposite side.
