Receptacle Housing for Dynamic D-3200 — 12 Circuits, 5.08 mm Pitch
The housing uses a 0.200" (5.08mm) pitch with a 0.300" (7.62mm) row spacing, giving it the creepage and clearance needed for power-level circuits without forcing an oversized footprint. A polarizing key prevents mis-mating with the wrong header.
This receptacle mates with a Dynamic D-3200 series pin header (male) of matching 12 positions and 5.08mm pitch. The polarizing key ensures the housing can only be mated with a header that has the complementary key slot, preventing assembly errors in multi-connector harnesses.
Comparison with 6-Position Sibling
The 12-position 3-917659-6 shares the same 0.200" (5.08mm) pitch, 2-row layout, and free-hanging crimp design as the 6-position 1-2069882-6. The only decision-relevant difference is circuit count — 12 positions vs 6 — so the choice comes down to how many circuits the harness requires. Both use the same terminal family and mate with the same header series.
