TE Connectivity AMP Connectors 325805-1
MPN325805-1
Active
CONN TERM RECT 300 MCM #1/2
$18.28Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesAmpower
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Ampower |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Standard |
| Wire gauge | 300MCM (kcmil) |
| Terminal style | Single Stud Hole |
| Contact material | Copper |
| Width - outer edges | 1.400\" (35.56mm) |
| Package | Bulk |
| Insulation | Non-Insulated |
| Termination | Crimp, Barrel |
| Stud (Tab size) | 1/2 Stud |
| Tab thickness | 0.160\" (4.06mm) |
| Contact finish | Tin |
| Length - overall | 2.690\" (68.33mm) |
| Diameter - ring ID | 0.515\" (13.08mm) |
| Diameter - barrel ID | 0.758\" (19.25mm) |
| Diameter - barrel OD | 0.951\" (24.16mm) |
