Open-top shunt for 0.100-inch headers
The 382811-2: This is a 2-position open-top shunt from the AMPMODU series, designed to jumper adjacent pins on a 0.100-inch pitch header. The open-top body gives probe access to the contact beams for test or programming. Gold plating at 15.0µin over the contact area handles repeated mating cycles without oxidation creep.
Mates with standard 0.025-inch square pins
The female sockets accept 0.025-inch square header pins on 0.100-inch centers. Common mating headers include TE AMPMODU MTE and other 0.100-inch breakaway headers.
RoHS compliant, blue housing
ROHS3 compliant per the current exemption list. The blue housing aids visual identification on the board.
