TE Connectivity AMP Connectors AMPMODU Mod II header, breakaway, order code 4-103329-0, 40 positions, single row, 0.100" (2.54 mm) pitch, 3 A, unshrouded, through-hole right-angle, solder termination, tin-lead mating and post finish.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.138\" (3.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 40 |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Tin-Lead |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 4-103329-0 is the 40-position single-row member of the AMPMODU Mod II breakaway header line, unshrouded with push-pull fastening.
The 4-103329-0 is listed as Obsolete.
The unshrouded design mates with standard AMPMODU Mod II receptacles or crimp housings at the same pitch.
