TE Connectivity AMP Connectors 4-1775099-2 — Pin Headers

4-1775099-2 TE Connectivity ATX Header, 8 Pos, 4.20 mm, 9 A

MPN4-1775099-2
Active

TE Connectivity AMP Connectors ATX series, 4-1775099-2, 8-position dual-row male pin header, 0.165" (4.20 mm) pitch, 9 A, 250 VAC, tin-plated brass contacts, four-wall shroud with locking ramp, through-hole solder, ivory PA9T insulator, tray.

$0.7000Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesATX
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

4-1775099-2 key specifications
ParameterValue
SeriesATX
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating250VAC
Current rating9A
Operating temperature-25°C ~ 85°C
Contact materialBrass
Insulation colorIvory
Insulation height0.504\" (12.80mm)
Insulation materialPolyamide (PA9T), Nylon 9T

All specifications

4-1775099-2 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
PackageTray
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.165\" (4.20mm)
Positions8
Row spacing - mating0.165\" (4.20mm)
Contact finish - postTin
Contact length - post0.126\" (3.20mm)
Contact finish - matingTin
Contact finish thickness - post120.0µin (3.05µm)
Contact finish thickness - mating120.0µin (3.05µm)

Product details

8 positions at 4.20 mm pitch — 9 A per contact

The 4-1775099-2 is an 8-position, dual-row male pin header from the TE ATX series, on a 0.165" (4.20 mm) pitch. The four-wall shroud with a locking ramp gives the mated pair a positive hold against vibration — useful in industrial panels or automotive sub-assemblies where the harness sees movement.

Tin plating at 120 µinch — moderate-cycle workhorse

That's thick enough to resist fretting corrosion in moderate-cycle applications (a few hundred mates over the product life) without the cost of gold. If your design cycles the connector more than 500 times, consider a gold-plated sibling in the ATX family.

Frequently asked questions

Where can I buy 4-1775099-2 and how is it quoted?

The 4-1775099-2 is sourced to order through independent distribution. No stock-holding claim; each order is sourced fresh.

Is 4-1775099-2 RoHS compliant?

Yes, it is ROHS3 compliant per the manufacturer's listing.

What is the pin pitch of 4-1775099-2?

The mating pitch is 0.165" (4.20 mm), with the same row-to-row spacing.
