TE Connectivity AMPMODU unshrouded breakaway header, 46 positions, 2 rows, 2.00 mm pitch, 30 µinch gold on mating contacts, through-hole solder termination, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 200VAC |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tray |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 46 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.102\" (2.60mm) |
| Overall contact length | 0.319\" (8.10mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 4-5176264-6: This saves board space but offers no strain relief; the mating half must be secured by other means in a vibration environment.
The 0.102 inch (2.60 mm) post length clears the board with room for a wave-solder fillet. Overall contact length is 0.319 inches (8.10 mm), with a 0.157 inch (4.00 mm) mating pin length — enough to engage a standard AMPMODU receptacle without bottoming out.
Available through independent distribution channels; sourced per RFQ.
Submit an RFQ for this part. No stock-holding claim is made; availability is verified per inquiry.
It is a 46-position header with a 2.00 mm mating pitch and 2.00 mm row spacing, dual-row layout.
