TE Connectivity AMP Connectors Micro MATE-N-LOK header, 4-794619-2, 12 positions, 3.00 mm pitch, right-angle through-hole, shrouded 4-wall, gold mating contacts, board lock, locking ramp, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.290\" (7.37mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.118\" (3.00mm) |
| Positions | 12 |
| Row spacing - mating | 0.118\" (3.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 4-794619-2: The board locks also help align the header during placement.
The solder tails are tin-plated, 100 µinch thick, which wets well during wave solder and is compatible with standard lead-free profiles.
It is ROHS3 compliant. Sourced per RFQ against the BOM quantity; availability and current pricing confirmed at quote time.
Buyers need to confirm application fit for board-to-wire connections.
Direct purchase intent; conversion is highest when sourcing is clear.
Stock availability drives immediate purchase decisions for production deadlines.
Price comparison is key for sourcing buyers filling BOM lines.
Lifecycle awareness prevents design or repair issues if part becomes obsolete.
Ensures proper mating for reliable connection; critical for design engineers and maintenance techs.
