TE Connectivity AMP Connectors Micro MATE-N-LOK header, 10 positions, 2 rows, 3.00mm pitch, shrouded 4-wall, surface-mount solder termination, gold mating finish 15.0µinch, locking ramp, UL94 V-0, -40°C to 105°C.
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.364\" (9.25mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Features | Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.118\" (3.00mm) |
| Positions | 10 |
| Row spacing - mating | 0.118\" (3.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 4-794637-0: This 10-position, dual-row header from the Micro MATE-N-LOK series mates with the matching crimp receptacle to create a wire-to-board interconnect.
ROHS3 compliant. The base product number is 794637.
The 4-794637-0 is sourced through independent distribution channels. No stock-holding claim is made here.
Two rows. The row spacing is also 3.00mm.
The mating pitch is 3.00mm (0.118 inches). The row spacing is the same 3.00mm.
