It mounts three ways — panel mount through a bulkhead with the front-side nut, through-hole solder to a PCB, or right-angle for a board-edge launch — which makes it flexible for chassis or PCB integration. The bayonet lock gives a quick quarter-turn mate, standard on BNC interfaces in test equipment, instrumentation, and RF patch panels.
The 50 Ohm impedance must match the cable and system to keep VSWR low. The 4 GHz upper frequency is the practical limit for a BNC interface; beyond that, the slot in the outer conductor starts to radiate. The board lock feature (a solder tab) holds the connector to the PCB during reflow and resists shear from cable strain. The filter and isolated features suggest this variant includes integrated filtering for EMI suppression and a separated ground path from the panel — check the product drawing for the exact filter network.
This BNC jack accepts a standard male BNC plug with bayonet coupling. The center contact is solder termination; the shield is also solder termination — no crimp ferrule.
