TE Connectivity BNC jack, 75 Ohm, 1 port, panel mount bulkhead, crimp termination, nickel body, gold center contact, 2 GHz, 500 mating cycles.
| Parameter | Value |
|---|---|
| Mounting | Panel Mount |
| Connector type | Jack, Female Socket |
| Fastening type | Bayonet Lock |
| Voltage rating | 500 V |
| Frequency - max | 2 GHz |
| Mounting feature | Bulkhead - Front Side Nut |
| Cable group | AT&T KS Cable |
| Operating temperature | -55°C~85°C |
| Body material | Zinc |
| Housing color | Silver |
| Dielectric material | Polyethylene (PE) |
| Center contact material | Beryllium Copper |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Includes | 6 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Gasket, 1 Lockwasher, 1 Nut |
| Impedance | 75Ohm |
| Body finish | Nickel |
| Mating cycles | 500 |
| Insertion loss | 0.15dB |
| Number of ports | 1 |
| Shield termination | Crimp |
| Contact termination | Crimp |
| Center contact plating | Gold |
The 413590-4: The 75 Ohm impedance marks it for video, broadband, and legacy telecom signal paths rather than the 50 Ohm standard used in wireless and test equipment.
No direct replacement order code is recorded in the lifecycle data. Buyers maintaining legacy video or telecom infrastructure should verify stock position before placing a build order.
Yes, TE Connectivity lists the 413590-4 as Obsolete. No official replacement part number has been published. Buyers should source through surplus or broker channels for existing builds.
