TE Connectivity AMP Connectors 487223-6 — FFC / FPC & Ribbon Connectors

TE 487223-6 FFC Housing, 24 Pos, 2.54mm, Active

MPN487223-6
Active

TE Connectivity AMP Connectors housing for female contacts, order code 487223-6, 24 positions, dual row, 0.100" (2.54mm) pitch, 300 V, 1.5 A, locking ramp, UL94 V-0 thermoplastic, bulk package.

$5.1300Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

487223-6 specifications
ParameterValue
Connector typeHousing for Female Contacts
Flat flex typeFFC, Discrete Wire
Voltage rating300 V
Current rating1.5 A
Wire gauge22-32 AWG
Operating temperature-65°C ~ 105°C
Housing colorBlack
Housing materialThermoplastic
Material flammability ratingUL94 V-0
NoteContacts Not Included
Pitch0.100\" (2.54mm)
PackageBulk
Rows2
Locking featureLocking Ramp
FFC, FCB thickness0.05-0.13mm
Insulation diameter0.025\" ~ 0.056\" (0.64mm ~ 1.42mm)
Positions24

Product details

Housing for 24-circuit FFC or discrete wire

The 487223-6 is the 24-circuit dual-row housing in TE Connectivity AMP Connectors' FFC / FPC & Ribbon Connectors line, accepting female contacts for FFC or discrete wire termination. Rated 300 V and 1.5 A per circuit with a 0.100" (2.54mm) pitch, the housing mates with a locking ramp and is molded from UL94 V-0 thermoplastic rated -65°C to 105°C.

Wire and FFC fit

The housing accepts 22-32 AWG discrete wire with an insulation diameter of 0.025" ~ 0.056" (0.64mm ~ 1.42mm) and FFC thickness from 0.05-0.13mm — contacts are ordered separately.

Frequently asked questions

What does the note 'Contacts Not Included' mean for the 487223-6?

The 487223-6 is a housing only — the mating female contacts must be ordered separately. The housing accepts 22-32 AWG wire or FFC with a thickness of 0.05-0.13mm.

What is the pitch and position count of the 487223-6?

The housing has 24 positions in a dual-row arrangement at 0.100" (2.54mm) pitch.
