TE Connectivity AMP Connectors 5-103669-2 — Pin Headers

5-103669-2 TE Connectivity AMPMODU MTE Header 3-Pos 2.54mm

MPN5-103669-2
Active

TE Connectivity AMP Connectors AMPMODU MTE series, 5-103669-2, 3-position single-row shrouded header, 0.100" (2.54mm) pitch, through-hole press-fit/solder termination, tin-plated contacts, 3 A rating, -65°C to 105°C, UL94 V-0.

$1.3800Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesAMPMODU MTE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

5-103669-2 key specifications
ParameterValue
SeriesAMPMODU MTE
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Holder
Current rating3A
Operating temperature-65°C~105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.535\" (13.60mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

5-103669-2 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationPress-Fit, Solder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions3
Contact finish - postTin
Contact length - post0.130\" (3.30mm)
Overall contact length0.545\" (13.84mm)
Contact finish - matingTin
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

The 5-103669-2: The through-hole mounting with press-fit or solder termination gives you flexibility: press-fit for high-reliability backplane assembly where rework is rare, or solder for prototyping and field repairs where a soldering iron is on hand.

Peer Comparison: 1394090-1

The closest functional alternative in the same family is the 1394090-1, a 6-position right-angle header with 0.112" (2.85mm) pitch and thinner tin plating (39.4 µin vs 100.0 µin). If your BOM calls for 3 positions and a 0.100" pitch, the 5-103669-2 is the direct match — the 1394090-1 requires a board layout change and a different mating connector.

Frequently asked questions

Where can I buy 5-103669-2?

Submit an RFQ for current pricing and lead time — availability is confirmed at quote, not held as stock.

What is the mating connector for 5-103669-2?

This header mates with AMPMODU MTE receptacle housings that accept crimp terminals.

Is 5-103669-2 RoHS compliant?

Yes, it is RoHS compliant per the manufacturer's listing.
