The 0.100" pitch sets the board layout: each row of through-hole solder posts is spaced 2.54 mm apart, with a post length of 0.130" (3.30mm) below the housing. The keying slot prevents cross-mating with unkeyed connectors. If the BOM needs more positions, the same footprint pattern extends by one position per step.
5-103673-3 TE Connectivity AMPMODU MTE Header, 4 Pos, 2.54mm
MPN5-103673-3
Active
TE Connectivity AMPMODU MTE header, 4 positions, 0.100" (2.54mm) pitch, right-angle through-hole, gold-plated mating contacts, shrouded with board lock and keying slot, rated 3 A per contact, UL94 V-0.
$1.0600Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesAMPMODU MTE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 4 |
| Contact finish - post | Tin |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the mating connector for 5-103673-3?
The mating half is a compatible AMPMODU MTE receptacle or cable assembly with a latch holder and keying slot. The 0.100" pitch and 4-position count must match.
