TE Connectivity AMPMODU MTE header, 5-103673-9, 10-position single-row right-angle through-hole, 0.100" (2.54mm) pitch, gold-plated mating contacts, shrouded with latch holder and board lock, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Lock, Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 10 |
| Contact finish - post | Tin |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 5-103673-9: This is a 10-position, single-row, right-angle header from the AMPMODU MTE series. The four-wall shroud and latch holder protect the pins during mating and keep the pair locked under vibration.
Right-angle through-hole termination with a 0.130" (3.30mm) post length — fits standard 1.6mm PCBs and leaves enough tail for a solid solder fillet.
The product drawing and electrical ratings are available through the TE Connectivity AMPMODU MTE series documentation. The base product number is 103673 — the full datasheet covers the series' mating interface, PCB layout dimensions, and crimp terminal specifications.
It mates with the AMPMODU MTE 10-position receptacle housing (e.g., 5-103674-9 or similar) loaded with the appropriate crimp socket contacts. The latch holder on the header engages the matching latch on the receptacle for a positive lock.
