Gold Mating Finish and Contact Reliability
The row spacing is 0.100 inch (2.54 mm), which matches the footprint pattern for the AMPMODU System 50 receptacle.
Sourced through independent distribution channels.
5-104069-1 TE AMPMODU System 50 Header, 20 Pos, 1.27mm Pitch
MPN5-104069-1
Active
TE Connectivity AMP Connectors AMPMODU System 50 header, 5-104069-1, 20-position dual-row, 0.050 inch (1.27 mm) pitch, right-angle through-hole, shrouded with latch holder, gold mating finish.
$6.4300Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesAMPMODU System 50
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 30VAC |
| Operating temperature | -65°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.290\" (7.37mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Guide |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Circular |
| Rows | 2 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.125\" (3.18mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What is the pitch and position count of 5-104069-1?
It is a 20-position, dual-row header with a 0.050 inch (1.27 mm) mating pitch. The row spacing is 0.100 inch (2.54 mm). All positions are loaded.
