Right-angle through-hole header for high-density board-to-board or cable interconnects
The 5-104069-4 is a 10-position, 2-row header from the AMPMODU System 50 series, with a 1.27mm pitch that suits dense board layouts. The shrouded 2-wall housing protects the gold-plated male pins from damage during mating and provides keying to prevent misinsertion.
Contact finish and temperature range for signal reliability
The UL94 V-0 rated thermoplastic housing meets flammability requirements for equipment inside enclosures.
Mating half and board footprint considerations
This header mates with AMPMODU System 50 receptacles (such as the 104069 series) that share the same 1.27mm pitch and 2-row layout. The 0.100" (2.54mm) row spacing and 0.125" (3.18mm) mating pin length define the receptacle's insertion depth and the mated stack height.
