60-Position, 0.050-Inch Pitch Right-Angle Header
The 5-104069-7 is a 60-position, dual-row, right-angle pin header from the AMPMODU System 50 series. The shrouded 2-wall housing with a latch holder keeps the mating connector locked under vibration, and the UL94 V-0 thermoplastic insulation handles the thermal environment of automotive, medical, and telecom equipment.
Footprint and Routing Constraints for Board Layout
At 0.050-inch pitch, the 60 positions occupy about 1.5 inches of board edge. The 0.100-inch (2.54 mm) post length and 0.125-inch (3.18 mm) mating pin length are standard for through-hole soldering; the board guide aids alignment during assembly. Rated 30 VAC, this header is suited for logic-level or sensor signals, not power distribution.
