TE Connectivity AMPMODU System 50 header, 5-104074-4, right-angle through-hole, 20 positions, single row, 0.050" (1.27 mm) pitch, gold-plated mating contacts, shrouded 2-wall, latch holder, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | AMPMODU System 50 |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 30VAC |
| Operating temperature | -65°C ~ 105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Features | Board Guide |
| Shrouding | Shrouded - 2 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Circular |
| Rows | 1 |
| Pitch | 0.050\" (1.27mm) |
| Positions | 20 |
| Contact finish - post | Tin |
| Contact length - post | 0.100\" (2.54mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.125\" (3.18mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 5-104074-4: This is a 20-position, single-row, right-angle header from the AMPMODU System 50 series, with a 0.050" (1.27 mm) pitch that sets the board footprint for dense signal routing. The shrouded 2-wall design and latch holder fastening keep the mating half aligned and locked under vibration — it mates with a matching receptacle or cable assembly that uses the same System 50 latch geometry.
Sourced to order through independent distribution. Submit an RFQ for current availability and pricing — no stock-holding claim, confirmed at quote time.
The mating pitch is 0.050" (1.27 mm), single row, 20 positions loaded.
Yes, it is RoHS Compliant.
