TE Connectivity AMP Connectors 5-104074-5 — Pin Headers

5-104074-5 TE Connectivity AMPMODU System 50 Header 25 Pos

MPN5-104074-5
Active

TE Connectivity AMP Connectors AMPMODU System 50 header, 5-104074-5, 25 positions, 1.27mm pitch, right-angle through-hole, gold-plated male pins, shrouded 2-wall, latch holder, UL94 V-0, RoHS.

$5.8600Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 5-104074-5 datasheet (PDF)
RoHSRoHS Compliant
SeriesAMPMODU System 50
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

5-104074-5 key specifications
ParameterValue
SeriesAMPMODU System 50
TypeMale Pin
MountingThrough Hole, Right Angle
Connector typeHeader
Fastening typeLatch Holder
Voltage rating30VAC
Operating temperature-65°C ~ 105°C
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0

All specifications

5-104074-5 additional specifications
ParameterValue
StyleBoard to Board or Cable
PackageTube
FeaturesBoard Guide
ShroudingShrouded - 2 Wall
TerminationSolder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeCircular
Rows1
Pitch0.050\" (1.27mm)
Positions25
Contact finish - postTin
Contact length - post0.100\" (2.54mm)
Contact finish - matingGold
Contact length - mating0.125\" (3.18mm)
Contact finish thickness - post150.0µin (3.81µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

25-position right-angle header for dense board-edge routing

The 5-104074-5 is a 25-position single-row header from TE's AMPMODU System 50 series, built for board-to-board or cable connections on a tight 0.050" (1.27mm) pitch.

Signal-level duty with a 30VAC ceiling

Rated 30VAC, this header is designed for signal-level interconnects, not power delivery. The 1.27mm pitch keeps board routing dense but limits per-contact current to low-signal levels.

Sourced through independent distribution channels against an RFQ. The closest functional cross-shop is the 1394090-1, but that part uses a 0.112" pitch and tin plating — a board spin is required.

Frequently asked questions

What is the mating connector for 5-104074-5?

This header mates with AMPMODU System 50 receptacles using the same 0.050" pitch and 25-position count. Confirm the mating half part number from the series catalog.
