TE Connectivity AMP Connectors 5-104362-5 — Pin Headers

5-104362-5 TE Connectivity AMPMODU MTE Header, 6 Pos

MPN5-104362-5
Active

TE Connectivity AMPMODU MTE header, 5-104362-5, 6-position single-row, 2.54 mm pitch, shrouded - 4 wall, through-hole, press-fit/solder termination, gold mating finish, 3 A, 267 V, UL94 V-0.

$2.0300Ref. price · indicative, final on quote
TE Connectivity AMP Connectors 5-104362-5 datasheet (PDF)
RoHSRoHS Compliant
SeriesAMPMODU MTE
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026

Specifications

5-104362-5 key specifications
ParameterValue
SeriesAMPMODU MTE
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Holder
Voltage rating267V
Current rating3A
Operating temperature-65°C~105°C
Contact materialBrass
Insulation colorBlack
Insulation height0.535\" (13.60mm)
Insulation materialThermoplastic

All specifications

5-104362-5 additional specifications
ParameterValue
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTube
FeaturesKeying Slot
ShroudingShrouded - 4 Wall
TerminationPress-Fit, Solder
ApplicationsAutomotive, General Purpose, Medical, Telecommunications
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions6
Contact finish - postTin
Contact length - post0.130\" (3.30mm)
Overall contact length0.550\" (13.97mm)
Contact finish - matingGold
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

6-Position, 2.54 mm Pitch, Shrouded Header

The 5-104362-5: The through-hole termination accepts both press-fit and solder assembly — the press-fit option eliminates the solder joint in high-reliability backplane or automotive builds where vibration cracks wave-solder fillets.

The part is RoHS compliant.

Peer Comparison: 1394090-1

Both carry a 3 A current rating and gold mating finish. The difference is in the contact length — 5-104362-5 has a 0.230" mating length and 0.130" post length; 1394090-1 uses a 0.318" mating length and 0.125" post. If your board stack-up or harness receptacle depth calls for a longer pin engagement, 1394090-1 is the one to check. Both are active and RoHS compliant.

Frequently asked questions

What is the pitch of 5-104362-5?

The mating pitch is 0.100" (2.54 mm), the standard 0.100-inch spacing for AMPMODU MTE headers.

Is 5-104362-5 RoHS compliant?

Yes, it is RoHS compliant per the manufacturer's status.
