TE Connectivity Economy Power header, order code 5-1123723-0, 10 positions, single row, 3.96 mm pitch, 7.5 A, 250 VAC, tin-plated mating contacts, through-hole, solder termination, shrouded with friction lock.
| Parameter | Value |
|---|---|
| Series | Economy Power |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Friction Lock |
| Voltage rating | 250VAC |
| Current rating | 7.5A |
| Operating temperature | -25°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.118\" (3.00mm) |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 1 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial, Lighting |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.156\" (3.96mm) |
| Positions | 10 |
| Contact finish - post | Tin |
| Contact length - post | 0.146\" (3.70mm) |
| Overall contact length | 0.567\" (14.40mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.303\" (7.70mm) |
The 5-1123723-0 is the 10-position member of TE's Economy Power header line, a single-row shrouded board-to-cable/wire connector with friction-lock retention.
The 3.00 mm insulation height and 0.146" post length are fixed across the series — the footprint and keying are shared, so the 10-position board layout carries over to other circuit counts in the Economy Power family.
The housing meets UL94 V-0 flammability rating. RoHS and REACH compliance documentation is provided by TE Connectivity on request.
