The 5-146130-6: The unshrouded, push-pull fastening allows easy mating and unmating in low-vibration environments. Rated 3A per contact at 30VAC, with a wide operating temperature range from -65°C to 125°C, this header suits industrial, automotive, and telecom applications where thermal cycling is a factor.
5-146130-6 TE Connectivity AMPMODU Mod II Header, 14 Pos
MPN5-146130-6
Active
TE Connectivity AMP Connectors AMPMODU Mod II, Header Breakaway, 14 Positions, 0.100" (2.54mm) Pitch, Dual Row, Surface Mount, Gold Mating Finish, Black LCP Housing, UL94 V-0
$2.2300Ref. price · indicative, final on quote
RoHSRoHS non-compliant
SeriesAMPMODU Mod II
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod II |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 30VAC |
| Current rating | 3A |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.090\" (2.29mm) |
| Insulation material | Liquid Crystal Polymer (LCP) |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Is 5-146130-6 RoHS compliant?
No, it is listed as RoHS non-compliant. Check your local regulations before ordering.
What is the current rating of 5-146130-6?
It is rated 3A per contact at 30VAC.
