TE Connectivity AMPMODU Mod IV receptacle, order code 5-147105-3, 6 positions, dual row, 0.100" (2.54mm) pitch, 2 A, gold-plated mating contacts, surface-mount, solder termination, bottom or top entry.
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod IV |
| Type | Female Socket |
| Mounting | Surface Mount |
| Connector type | Receptacle, Bottom or Top Entry |
| Fastening type | Push-Pull |
| Current rating | 2A |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.265\" (6.73mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) |
| Features | Pick and Place |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 5-147105-3 is a 6-circuit dual-row receptacle from the AMPMODU Mod IV series, accepting 0.100" (2.54mm) pitch headers from the same family. Gold-plated mating contacts rated 2 A per circuit, with a tin-plated post finish for solder termination.
The style is Board to Board or Cable, per the AMPMODU Mod IV series specification.
