TE AMPMODU MTE header, order code 5-147278-6, 7 positions, single row, 0.100" (2.54 mm) pitch, 3 A, gold-plated mating contacts, surface-mount right-angle, solder termination, shrouded 4-wall, latch holder, board lock, keying slot.
TE AMPMODU MTE 5-147278-6 Header, 7-Pos 2.54mm
MPN5-147278-6
Active
TE AMPMODU MTE header, order code 5-147278-6, 7 positions, single row, 0.100" (2.54 mm) pitch, 3 A, gold-plated mating contacts, surface-mount right-angle, solder termination, shrouded 4-wall, latch holder, board lock, keying slot.
$3.0509Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR) |
| Features | Board Lock, Keying Slot, Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 7 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What is the style of the 5-147278-6 header?
The 5-147278-6 is listed as a Board to Board or Cable style header.
What compliance documentation is available for the 5-147278-6?
The header carries a UL94 V-0 material flammability rating on the thermoplastic housing.
