TE Connectivity AMPMODU MTE, 5-position single-row header, 0.100" (2.54 mm) pitch, surface-mount right-angle, shrouded, gold mating contacts, 3 A, UL94 V-0, RoHS
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Board Lock, Keying Slot, Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
A close peer is the 1394090-1, also a single-row right-angle header from the same AMPMODU MTE family, but with 6 positions and a 0.112" (2.85 mm) pitch — slightly wider spacing. The 1394090-1 uses tin-on-tin contacts throughout, while the 5-147323-4 has gold on the mating face. For applications requiring higher mating cycle life or better corrosion resistance, the gold-plated 5-147323-4 is the stronger choice.
The header mates with AMPMODU MTE receptacles that accept 26-30 AWG crimp terminals.
We source the 5-147323-4 through independent distribution channels.
The 5-147323-4 mates with AMPMODU MTE receptacles that accept 26-30 AWG crimp terminals.
