TE Connectivity AMP Connectors AMPMODU MTE header, 5-147324-7, 8 positions, 0.100" (2.54mm) pitch, surface-mount right-angle, shrouded 4-wall, tin-plated contacts, 3A, active production.
| Parameter | Value |
|---|---|
| Series | AMPMODU MTE |
| Type | Male Pin |
| Mounting | Surface Mount, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Current rating | 3A |
| Operating temperature | -65°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.200\" (5.08mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Board Lock, Keying Slot, Solder Retention |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | Automotive, General Purpose, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The board lock and solder retention features anchor the header during reflow and resist shear force from cable strain.
Termination is solder-only (SMD), with tin-plated posts (100.0µin thickness) that wet well during reflow. The contact material is brass, which offers good solderability and mechanical strength for the pin.
Yes. The 0.100" pitch, single-row configuration, and latch holder are designed to mate with AMPMODU MTE receptacles. The keying slot prevents mis-mating with non-keyed or differently keyed housings.
