Gold mating finish and 2 A rating — signal-level reliability
The 5-147726-6: The mating contacts are gold-plated (10.0 µin minimum thickness) over phosphor bronze base metal, while the solder tails are tin-plated (150.0 µin).
5-147726-6 TE Connectivity AMPMODU Mod IV 7-Position Female
MPN5-147726-6
Active
TE Connectivity AMPMODU Mod IV, 5-147726-6, 7-position single-row female socket header, 0.100" (2.54 mm) pitch, through-hole solder termination, gold mating finish, 2 A rated, UL94 V-0 black polyester housing.
$1.6600Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesAMPMODU Mod IV
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod IV |
| Type | Female Socket |
| Mounting | Through Hole |
| Connector type | Receptacle, Bottom or Top Entry |
| Fastening type | Push-Pull |
| Current rating | 2A |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.265\" (6.73mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tube |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 7 |
| Contact finish - post | Tin |
| Contact length - post | 0.125\" (3.18mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 10.0µin (0.25µm) |
Product details
Frequently asked questions
Is 5-147726-6 RoHS compliant?
Yes, the 5-147726-6 is RoHS compliant per TE Connectivity's current compliance status.
What is the mating connector for 5-147726-6?
The mating half is a through-hole or vertical header with square pins; the exact part number depends on the pin length and plating required.
