TE 5-1747145-4 Dynamic DZ5200 Header, 4-Position, 30A, 600V, 10.16mm Pitch
MPN5-1747145-4
Active
TE Connectivity 5-1747145-4, Dynamic DZ5200 series, board-to-cable header, 4 positions, 1 row, 0.400in (10.16mm) pitch, 30A per contact, 600V, through-hole right-angle, gold on mating contacts, tin on posts, shrouded 4-wall, board lock, -55°C to 105°C, tube package.
$10.9500Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Dynamic DZ5200 |
| Type | Tab |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Detent Lock |
| Voltage rating | 600V |
| Current rating | 30A |
| Operating temperature | -55°C~105°C |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.630\" (16.00mm) |
| Insulation material | Thermoplastic, Polyester, Glass Filled |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
| Features | Board Guide, Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose, Industrial |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.400\" (10.16mm) |
| Positions | 4 |
| Contact finish - post | Tin |
| Contact length - post | 0.150\" (3.81mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 8.00µin (0.203µm) |
Frequently asked questions
What style is the 5-1747145-4?
The connector is classified as Board to Cable/Wire — a tab-header configured for mating with a compatible wire-housing receptacle to make a cable-side or panel-side connection.
