TE Connectivity AMP Connectors 5-1971846-3 — Pin Headers

TE 5-1971846-3 RAST 5 Header, 3 Pos, 20 A, 5.00 mm

MPN5-1971846-3
Active

TE Connectivity RAST 5 tab header, 5-1971846-3, 3 positions, single row, 5.00 mm pitch, 20 A, 250 VAC, through-hole solder, silver-plated contacts, shrouded with latch holder.

$1.6000Ref. price · indicative, final on quote
RoHSRoHS Compliant
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

5-1971846-3 key specifications
ParameterValue
TypeTab
MountingThrough Hole
Connector typeHeader
Fastening typeLatch Holder
Voltage rating250VAC
Current rating20A
Operating temperature-40°C~120°C
Contact materialCopper Alloy
Insulation colorNatural
Insulation height0.504\" (12.80mm)
Insulation materialPolyamide (PA), Nylon
Material flammability ratingUL94 V-0

All specifications

5-1971846-3 additional specifications
ParameterValue
StyleBoard to Cable/Wire
PackageBag
FeaturesBoard Guide, Glow Wire Compliant
ShroudingShrouded - 4 Wall
TerminationSolder
ApplicationsGeneral Purpose
Contact shapeRectangular
Rows1
Pitch0.197\" (5.00mm)
Positions3
Contact finish - postSilver
Contact length - post0.138\" (3.50mm)
Contact finish - matingSilver

Product details

The TE Connectivity 5-1971846-3 is a 3-position, single-row RAST 5 tab header on a 5.00 mm pitch. Rated 20 A per circuit at 250 VAC, this is a power-level interconnect for board-to-cable/wire applications in appliances, industrial controls, and lighting.

The silver plating on both the mating contact and the solder post is a step up from tin: silver carries the 20 A rating with lower contact resistance than tin at this current level, though it tarnishes more readily in high-humidity environments. The glow wire compliant feature means the housing material passes the IEC 60695-2-11 glow-wire test, a requirement for unattended appliances and white goods where the connector sits near a potential ignition source.

Frequently asked questions

Is 5-1971846-3 glow wire compliant?

Yes, the Features field lists Glow Wire Compliant — the housing material passes the glow-wire test per IEC 60695-2-11, making it suitable for appliance and white goods applications where this compliance is required.

What is the mating connector for 5-1971846-3?

This is a RAST 5 tab header — it mates with the matching RAST 5 receptacle housing that accepts the corresponding crimp terminals. The latch holder on the header engages with the latch on the receptacle for positive retention.

What is the price of 5-1971846-3?

Pricing is confirmed at quote time against your specific BOM quantity and delivery requirements. Submit an RFQ through the storefront for a current price.
