The 6.00 mm pitch and 8.10 mm row spacing give it the footprint for medium-current power distribution — think appliance wiring, lighting ballasts, or HVAC control boxes where a glow-wire-rated interconnect is specified.
Pitch, Positions, and the Board Fit
At 6.00 mm pitch, this housing sits on a wider grid than the 5.08 mm pitch of the 1-2069882-6 (a 6-position sibling from the same family). The extra 0.92 mm per position gives more creepage for higher-voltage layouts and room for larger-gauge crimp terminals. The 10 positions here match a 10-circuit BOM line; if your circuit count is lower, the 6-position 1-2069882-6 saves board space at the same row spacing.
Glow Wire and Compliance Angle
The Glow Wire Compliant marking means the housing material (glass-filled polyamide) passes the IEC 60335-1 glow-wire test at 850°C without igniting. That is a hard requirement for appliances sold into European and Asian markets — washing machines, cooktops, air handlers — where a glowing resistor or loose terminal must not start a fire inside the enclosure. RoHS compliance is confirmed on the lifecycle record.
