30-Position Dual-Row Receptacle for Board-to-Board Stacking
The 5-534204-4 is a 30-position dual-row female socket receptacle from the AMPMODU Mod II series, designed for board-to-board interconnects on a 0.100" (2.54mm) pitch. The kinked pin termination provides a positive mechanical lock in the plated through-hole before reflow.
Pitch, Position Count, and Mating Compatibility
At 0.100" pitch with 30 positions loaded across two rows (row spacing also 0.100"), this receptacle mates with standard AMPMODU Mod II 0.100" square-pin headers. The guide pin ears on the housing help align the pair during blind-mate assembly.
