TE Connectivity AMP Connectors Micro MATE-N-LOK header, 5-794618-2, 22-position, 3.00 mm pitch, right-angle through-hole, shrouded 4-wall, tin-plated male pins, locking ramp, board lock, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Micro MATE-N-LOK |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | Varies by Wire Gauge |
| Operating temperature | -40°C ~ 105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.290\" (7.37mm) |
| Insulation material | Polyamide (PA), Nylon |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Features | Board Lock |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.118\" (3.00mm) |
| Positions | 22 |
| Row spacing - mating | 0.118\" (3.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 5-794618-2: This is a 22-position, 2-row header from the Micro MATE-N-LOK series, pitched at 3.00 mm on both the row and column spacing.
That temperature range covers most indoor industrial gear, automotive interior, and telecom equipment. The ROHS3 compliance is current — no lead or restricted substances to flag for a BOM review.
This header mates with a Micro MATE-N-LOK receptacle housing that accepts crimp terminals. The mating half uses the same 3.00 mm pitch and locking ramp interface — look for a receptacle with 22 positions in the same series.
