22-Position, 3.00 mm Pitch, Right-Angle Header for Wire-to-Board
The 5-794620-2: This is a 22-position, 2-row, right-angle through-hole header from the TE Micro MATE-N-LOK series, designed for board-to-cable/wire applications. The 3.00 mm pitch and 3.00 mm row spacing match the standard Micro MATE-N-LOK receptacle family, making it a direct fit for harness builds that already use that system.
Gold Mating Finish and Board Lock for Reliable Termination
The mating contacts are finished with 30.0 µin (0.76 µm) of gold over a brass base, which supports repeated mating cycles without corrosion or resistance drift. The solder tails are tin-plated at 100.0 µin (2.54 µm) for good solder wetting.
