TE Connectivity AMPMODU breakaway header, 20 positions, 2.00 mm pitch, through-hole, unshrouded, 30 µinch gold mating finish, UL94 V-0
| Parameter | Value |
|---|---|
| Series | AMPMODU |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Voltage rating | 200VAC |
| Operating temperature | -40°C~105°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Tray |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 20 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.102\" (2.60mm) |
| Overall contact length | 0.319\" (8.10mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 5176264-9: The breakaway construction means you can snap the strip to a shorter length for a custom circuit count, though this one ships fully populated at 20 positions.
Through-hole solder termination, vertical orientation. The 1.50 mm insulation height keeps the header low-profile on the board — useful when the mating receptacle sits close to the PCB.
It mates with any standard 2.00 mm pitch AMPMODU receptacle — typically a 20-position, dual-row socket housing. The unshrouded header has no keying, so the receptacle must have the correct circuit count and row spacing (0.079" / 2.00 mm) to align.
