TE Connectivity AMP Connectors header, order code 521383-3, 3 positions, single row, 0.197" (5.00mm) pitch, 250VAC, tin-plated mating contacts, through-hole, solder termination.
| Parameter | Value |
|---|---|
| Type | Tab |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250VAC |
| Operating temperature | -40°C ~ 120°C |
| Contact material | Brass |
| Insulation height | 0.504\" (12.80mm) |
| Insulation material | Polyamide (PA66), Nylon 6/6 |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Features | Board Guide, Glow Wire Compliant |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.197\" (5.00mm) |
| Positions | 3 |
| Contact finish - post | Tin |
| Contact length - post | 0.138\" (3.50mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 521383-3 is the 3-circuit member of TE Connectivity AMP Connectors' shrouded header line, a board-to-cable/wire style with a 4-wall shroud and latch holder for secure mating. Rated at 250VAC with tin-plated mating contacts, the header mounts through-hole and terminates by solder.
The 521383-3 is supplied by TE Connectivity AMP Connectors.
The 521383-3 is a Board to Cable/Wire style header with a shrouded 4-wall design and latch holder for secure mating.
