TE Connectivity AMP Connectors 521383-5, a 5-position single-row shrouded header, 5.00 mm pitch, through-hole solder termination, tin-plated contacts, UL94 V-0 housing, rated 250 VAC, -40°C to 120°C.
| Parameter | Value |
|---|---|
| Type | Tab |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250VAC |
| Operating temperature | -40°C ~ 120°C |
| Contact material | Brass |
| Insulation height | 0.504\" (12.80mm) |
| Insulation material | Polyamide (PA66), Nylon 6/6 |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Features | Board Guide, Glow Wire Compliant |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Applications | General Purpose |
| Contact shape | Rectangular |
| Rows | 1 |
| Pitch | 0.197\" (5.00mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact length - post | 0.138\" (3.50mm) |
| Contact finish - mating | Tin |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
The 521383-5: Through-hole solder termination provides a robust mechanical anchor to the PCB, with a 0.138" (3.50 mm) post length for standard board thicknesses.
The 150 µin thickness exceeds standard tin flash, providing better wear resistance in repeated insertions.
No official cross-reference or direct replacement is recorded for the 521383-5. The base product number 521383 covers the series; verify the position count, pitch, and shroud configuration against any candidate part before substituting.
