BNC Plug for RG-59/62 Coax — Kit Includes Contact, Ferrule, Spacer
The 5227079-7: It ships as a 4-piece kit: the connector body, one center contact, one ferrule, and one spacer — everything needed for a single field termination.
TE Connectivity 5227079-7 BNC Plug, 50 Ohm, 4 GHz, Obsolete
MPN5227079-7
Obsolete
TE Connectivity BNC plug, male pin, 50 Ohm, 4 GHz, 500 V, crimp termination, bayonet lock, free-hanging, bulk package.
$3.9100Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Connector type | Plug, Male Pin |
| Fastening type | Bayonet Lock |
| Voltage rating | 500 V |
| Frequency - max | 4 GHz |
| Cable group | RG-59, 59A, 59B, 62, 62A, 62B |
| Operating temperature | -55°C ~ 85°C |
| Body material | Brass |
| Housing color | Silver |
| Dielectric material | Polyethylene (PE) |
| Center contact material | Brass |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Includes | 4 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Spacer |
| Impedance | 50 Ohms |
| Body finish | Nickel |
| Mating cycles | 500 |
| Insertion loss | 0.2dB |
| Number of ports | 1 |
| Shield termination | Crimp |
| Contact termination | Crimp |
| Center contact plating | Gold |
Product details
Frequently asked questions
Where can I buy the 5227079-7?
Submit a request for quote (RFQ) for current pricing and availability — no stock-holding or lead-time claim is made here.
What cable groups does the 5227079-7 support?
The 5227079-7 is designed for RG-59, RG-59A, RG-59B, RG-62, RG-62A, and RG-62B coaxial cables. The kit includes the correct ferrule and spacer for these cable types.
