TE Connectivity AMP Connectors 52943-1
MPN52943-1
Active
$0.5300Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | PIDG |
| Mounting | Free Hanging (In-Line) |
| Terminal type | Spring, Snap |
| Wire gauge | 10-12 AWG |
| Color | Yellow |
| Contact material | Phosphor Bronze |
| Width - outer edges | 0.406\" (10.31mm) |
| Material - insulation | Polyamide (PA), Nylon |
| Features | Serrated Termination |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Insulation | Insulated |
| Termination | Crimp |
All specifications
| Parameter | Value |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Stud (Tab size) | 10 Stud |
| Contact finish | Tin |
| Length - overall | 1.100\" (27.94mm) |
| Insulation diameter | 0.150\" ~ 0.250\" (3.81mm ~ 6.35mm) |
| Length - termination | 0.601\" (15.27mm) |
| Tongue inside opening | 0.190\" (4.83mm) |
| Length - ring center to termination | 0.276\" (7.01mm) |
