TE Connectivity AMPMODU Mod IV receptacle, order code 534267-6, 26 positions, dual row, 0.100" (2.54mm) pitch, gold mating contacts, through-hole solder termination, black polyester housing.
TE AMPMODU Mod IV 534267-6 Receptacle, 26 Pos, 2.54mm
MPN534267-6
Active
TE Connectivity AMPMODU Mod IV receptacle, order code 534267-6, 26 positions, dual row, 0.100" (2.54mm) pitch, gold mating contacts, through-hole solder termination, black polyester housing.
$3.8696Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | AMPMODU Mod IV |
| Type | Female Socket |
| Mounting | Through Hole |
| Connector type | Receptacle, Bottom or Top Entry |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.265\" (6.73mm) |
| Insulation material | Polyester, Glass Filled |
| Style | Board to Board |
| Package | Tube |
| Termination | Solder |
All specifications
| Parameter | Value |
|---|---|
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 26 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact length - post | 0.125\" (3.18mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What compliance documentation is available for 534267-6?
The 534267-6 is listed under the AMPMODU Mod IV series. RoHS and REACH compliance details are provided in the manufacturer documentation for this base product number.
